ALLEN & HEATH DX012
Produktinformationen "ALLEN & HEATH DX012"
DX012 provides remote output expansion for Qu*, SQ, Avantis and dLive mixers, and for AHM audio matrix processors.
12 XLR Outs
Flexible switching options between balanced, relay protected analogue and stereo AES digital on outputs 5-12.
AES Compatible
AES outputs globally switchable between 44.1kHz,
48kHz, 88.2kHz or 96kHz.
Redundant & Cascade Modes
Redundant mode supports dual-cable connection to compatible hardware. Cascade mode allows daisy-chaining of up to 2 DX Expanders on each DX port.
Plug-and-Play
No configuration required, just connect to your mixer and you’re ready to go. Firmware updates are handled automatically by the mixer.
The DX012 provides 12 XLR outputs, with three configuration options:
- 12 analogue line outputs
- 8 analogue line outputs + 4 stereo AES outputs
- 4 analogue line outputs + 8 stereo AES outputs
*96kHz Qu models only
