ALLEN & HEATH QU-5

19″ Rack KitThe rack kit prepares Qu-5 for fitting in standard 19” rack.QU-5-RK19/X – Qu-5 / Qu-5D 19″ Rack Mount Kit

The steel tablet bracket screws into the rear of your Qu – perfect for using an iOS or Android device running Qu MixPad to extend touchscreen control and visual feedback.

AB168 is a 48kHz portable remote AudioRack for use with Qu, Avantis and SQ mixers, and with AHM audio matrix processors.16 Mic Preamps+60dB of gain, Phantom Power indicators and -20dB pad for line level sources.8 XLR Line OutsBalanced, relay protected line outputs on XLR.Expander PortFor daisy-chaining 2 compatible Expanders or connection to ME personal mixers.Plug-and-PlayNo configuration required, just connect to your mixer and you’re ready to go. Firmware updates are handled automatically by the mixer.Ready for the StageThe Expander’s rugged design, with hard-wearing rubber bumpers, allows it to be placed directly on the stage floor during performances. Weighing in at just 4.8kg and featuring a sturdy carry handle, the AB168 offers the convenience and portability needed in rental, education, houses of worship and many other environments. An optional 4U rack mounting kit is available for installation in 19-inch racks.Put It Where You Need ItThe AB168 can be placed up to 100m away from the mixer for maximum flexibility of positioning. The unit connects over a single Cat5 cable to the mixer or upstream Expander. A second port is provided for daisy-chaining to another compatible expander or for connection to a ME personal mixing system.

AR2412 is a 48kHz, 24 XLR input, 12 XLR output AudioRack, compatible with Qu, Avantis and SQ mixers, and with the AHM audio matrix processors.24 Mic Preamps+60dB of gain with -20dB pad for line level sources.12 Line OutsBalanced, relay protected line outputs on XLR.Expander & Monitor PortsDedicated ports for connection to an AR84 or AB168, and to the ME Personal Mixing System.Plug-and-PlayNo configuration required, just connect to your mixer and you’re ready to go. Firmware updates are handled automatically by the mixer.Put It Where You Need ItThe AR2412 can be placed up to 100m away from the mixer for maximum flexibility of positioning and includes rack ears for mounting in a 3U 19″ rack space.The unit connects over a single Cat5 cable to the mixer or upstream Expander. A second port is provided for daisy-chaining to another compatible expander or for connection to a ME personal mixing system.
