ALLEN & HEATH AHM-32

Rahmen 478615 nicht im Lieferumfang / Frame 478615 not includedWall or plinth mountedEU versionblackCompatible with Decora and MK Elements faceplatesInterface with dLive, Avantis and AHM-64 systems via TCP/IPDual function push & Turn rotary encoderLCD DisplayPowered via PoEThe remote controller shall be of a fixed installation type with 1 rotary encoder and 1 LCD display. The rotary encoder shall be dual function with the second function being accessed via a push and turn action. There shall be a fast Ethernet connection via an RJ45 connector. Connection of the controller shall be direct to the dLive Mixrack/Surface, Avantis mixer or AHM-64 Matrix Processor via standard Cat5 data infrastructure. Alternatively, it shall be capable of multiple parallel connections using an Ethernet switch. Configuration and programming of the controller shall be via AHM System Manager or dLive Director Software (PC or Mac), or via an Avantis mixer or dLive Surface. The controller shall be powered by the Cat5 control cable via aPoE enabled device. The controller shall be compatible with both PoE standards 802.3af (15.4W at source) and 802.3at (30W at source). The maximum power consumption of the controller shall be 2.5W. The remote controller shall be used wall/plinth mounted with multiple options to suit varying pattress box standards. These options shall include compatibility with Decora and Mk Elements faceplates when integrating with varying architectural finishes. Recommended operating temperature for the controller shall be 0 to 35 degrees Celsius.The controller shall be the Allen & Heath IP1. Dimensions and Weights Width x Depth x Height x Weight IP1 - EU 50 x 32 x 50 mm (2" x 1.3" x 2") x 70g (2.5 ounces)

AR84 is an 8 XLR input, 4 XLR output AudioRack, compatible with Qu, Avantis and SQ mixers, and with AHM audio matrix processors.8 Mic Preamps+60dB of gain with -20dB pad for line level sources.4 Line OutsBalanced, relay protected line outputs on XLR.Plug-and-PlayNo configuration required, just connect to your mixer and you’re ready to go. Firmware updates are handled automatically by the mixer.Put It Where You Need ItThe AR84 can be placed up to 100m away from the mixer for maximum flexibility of positioning, and is fitted with rack ears for installation in a 1U 19″ rack space. The AR84 connects over a single Cat5 cable to the mixer or upstream Expander.

The Processing Expansion Module provides up to 12 channels of acoustic echo cancellation (AEC) or 8 instances of feedback suppression (FBS) for AHM-32. FeaturesUp to 12 Channels of AEC150ms FIR Adaptive FilterFar-End AGC (Automatic Gain Control)Residual Echo NLP (non-linear processing)Background Noise ReductionNear-End gatingSpeech-Shaped Comfort NoiseUp to 8 instances of FBS25 configurable live or fixed bandsBias adjustmentsMono or stereo Zone supportReset All Bands available for controllersAECAssigned via Inserts on Input Channels. One AEC reference is available per setup. Multi-mic scenarios supported for up to 12 microphones in a single setup.With remote attendance of meetings and conferences becoming increasingly common, high quality audio is critical to ensure intelligibility for all attendees.Remote participants often experience distracting echoes – caused by their voice being played over speakers in the conference room, picked up by multiple microphones and broadcast back to the caller – which can seriously impede the clarity of the audio, and the flow of the meeting.Allen & Heath’s Acoustic Echo Cancellation intelligently detects the “echo” in the remote participants feed, plus any residual effects caused by room acoustics, and utilises dedicated hardware processing to minimise the unwanted audio.The result? A clearer, more comfortable listening experience for everyone in the meeting!FBSAssigned via Inserts on Zone Channels. Up to 25 bands of live or fixed feedback suppression. Mono or stereo Zones supported.Not every voicelift or sound reinforcement scenario is perfect. Not every person knows the best mic handling technique.Feedback suppression allows us to diminish annoying or harmful frequencies that can damage sound equipment or distract audience members.With up to 8 instances of FBS each with up to 25 bands of feedback detection and suppression, even the most troublesome systems can be tamed.User InterfaceAll the parameters you need, for any mode. AHM’s System Manager provides easy and accessible control over FBS and AEC.

SQ Dante 32×32 provides any SQ / SQ+ mixer or AHM processor with a full 32×32 channel, 96kHz or 48kHz interface to a Dante network.Expand Your System With DanteAn SQ or AHM unit fitted with the Dante option card can seamlessly connect to DT expanders, wireless systems, amplifiers, preamps and any other devices on your Dante network, making full use of high-resolution 96kHz audio.The SQ Dante card can be switched between 96kHz or 48kHz to accommodate Dante networks running at either sample rate. In addition to facilitating system integration, the card also enables digital splits and affordable multitrack recording direct to a computer.Add Dante to AHM Matrix ProcessorsThe SQ Dante 32×32 card is the perfect partner to the AHM-32 and AHM-16 Audio Matrix Processors.As well as making it easy to integrate AHM processors into existing Dante networks, it also enables use of our Dante enabled expanders, including the compact and portable DT22, DT02 and DT20, the wallmountable DT164-W, and the DT168 stagebox.

SQ SLink bietet die Möglichkeit, jedem SQ- oder AHM-Mixer einen intelligenten SLink-Port hinzuzufügen.Für SQBei SQ läuft die Optionskarte unabhängig vom integrierten SLink-Port, sodass zwei verschiedene Allen & Heath-Protokolle gleichzeitig in einem System verwendet werden können. Mit zwei SLink-Ports ist es jetzt möglich, einen SQ mit jedem ME-Personal-Monitoring-System, DX-, GX- oder dSnake-Expander zu kombinieren.Jede mit einer SLink-Karte ausgestattete SQ-Konsole kann auch direkt an ein Qu-, SQ-, Avantis- oder dLive-System angeschlossen werden, wodurch FOH-/Monitor-Splits, Broadcast-Feeds und mehr ermöglicht werden.Für AHMDie SQ SLink-Karte bietet AHM-16- und AHM-32-Prozessoren Zugriff auf die Everything I/O-Reihe von Audio-Expandern und fügt AHM-64 weitere I/O-Funktionen hinzu.Auf AHM-64 läuft die Optionskarte unabhängig vom integrierten SLink-Port, sodass zwei verschiedene Allen & Heath-Protokolle gleichzeitig in einem System verwendet werden können.

Rahmen 465432nicht im Lieferumfang / Frame 465432 not included IP4 is a simple programmable wallplate, giving the non-technical user convenient, easy control via 4 illuminated buttons.IP4 is compatible with Decora and MK Elements faceplates. Simple to UseIP4 is designed with the non-technical user in mind, and can control zone level, source selection, mutes, level adjustment, scene/preset recall, and more.Low MaintenanceThe IP4 automatically matches firmware with connected devices for easy install and system maintenance.Mix and MatchMultiple IP Controllers can be connected to an AHM system to provide control exactly where needed.Use IP controllers of different flavors to suit the needs of your end users, even letting one controller change what other controllers are doing to reflect changes in the space.ConnectIP4 interfaces with the AHM system via standard TCP/IP Network connections and can be networked with other controllers, computers and third party devices using a standard Ethernet infrastructure.ConfigureIP4’s controls and functions are configured using AHM System Manager.

The DX88 provides 8 inputs and 8 outputs on Phoenix / Euroblock connectors for fixed installations and is an easy way to add local or remote expansion to AHM Audio Matrix Processors.8 Ins + OutsEight mic/line inputs with +60dB of gain, phantom power and -20dB pad, and eight line outputs, all on Phoenix/Euroblock connectors.RackmountableA rackmount kit is available for installing two DX88 expanders together. DX88 can also be installed alongside a GPIO or DX Hub with an additional kit.Cascade ModeCascade mode allows daisy-chaining of up to 2 DX Expanders on each DX port.Plug-and-PlayNo configuration required, just connect to your mixer and you’re ready to go. Firmware updates are handled automatically by the mixer.Easily Add Phoenix / Euroblock Inputs and Outputs via a DX ConnectionDX88 is a 96kHz DX expander enabling convenient placement of 8 mic/line inputs and 8 line outputs – via standard Phoenix / Euroblock connectors – wherever you need to get additional analogue audio in and out of a fixed install.Put It Where You Need ItThe DX88-P can be placed up to 100m away from the mixer for maximum flexibility of positioning.The expander connects via a single Cat5e cable to the mixer or upstream DX Expander via the DX A port. A second RJ45 port, DX B, is provided for daisy-chaining to a downstream DX Expander for additional remote I/O.Rack Mount KitAn optional rack mount kit is available for installation of up to two DX88-P units in a 1U 19″ slot to interface with analogue equipment such as an AV switcher.The DX88-P can also be rack mounted alongside a DX Hub or GPIO module by combining the optional rack kit with the DX Hub / GPIO rack kit.

Rahmen 465432 nicht im Lieferumfang / Frame 465432 not includedWall or plinth mountedEU versionwhiteCompatible with Decora and MK Elements faceplatesInterface with dLive, Avantis and AHM-64 systems via TCP/IPDual function push & Turn rotary encoderLCD DisplayPowered via PoEThe remote controller shall be of a fixed installation type with 1 rotary encoder and 1 LCD display. The rotary encoder shall be dual function with the second function being accessed via a push and turn action. There shall be a fast Ethernet connection via an RJ45 connector. Connection of the controller shall be direct to the dLive Mixrack/Surface, Avantis mixer or AHM-64 Matrix Processor via standard Cat5 data infrastructure. Alternatively, it shall be capable of multiple parallel connections using an Ethernet switch. Configuration and programming of the controller shall be via AHM System Manager or dLive Director Software (PC or Mac), or via an Avantis mixer or dLive Surface. The controller shall be powered by the Cat5 control cable via aPoE enabled device. The controller shall be compatible with both PoE standards 802.3af (15.4W at source) and 802.3at (30W at source). The maximum power consumption of the controller shall be 2.5W. The remote controller shall be used wall/plinth mounted with multiple options to suit varying pattress box standards. These options shall include compatibility with Decora and Mk Elements faceplates when integrating with varying architectural finishes. Recommended operating temperature for the controller shall be 0 to 35 degrees Celsius.The controller shall be the Allen & Heath IP1. Dimensions and Weights Width x Depth x Height x Weight IP1 - EU 50 x 32 x 50 mm (2" x 1.3" x 2") x 70g (2.5 ounces)

SQ Dante provides any SQ / SQ+ mixer or AHM processor with a full 64×64 channel, 96kHz or 48kHz interface to a Dante network.Expand Your System With DanteAn SQ or AHM unit fitted with the Dante option card can seamlessly connect to DT expanders, wireless systems, amplifiers, preamps and any other devices on your Dante network, making full use of high-resolution 96kHz audio.The SQ Dante card can be switched between 96kHz or 48kHz to accommodate Dante networks running at either sample rate. In addition to facilitating system integration, the card also enables digital splits and affordable multitrack recording direct to a computer.Add Dante to AHM Matrix ProcessorsSQ Dante V2& V3 share all the features and specifications of the V1 module, with no differences for SQ users*, but the V2 & V3 modules can also be fitted and used in an AHM matrix processor.*SQ firmware V1.5 or higher required.

Rahmen 478615 nicht im Lieferumfang / Frame 478615 not includedIP4 is a simple programmable wallplate, giving the non-technical user convenient, easy control via 4 illuminated buttons.IP4 is compatible with Decora and MK Elements faceplates.Simple to UseIP4 is designed with the non-technical user in mind, and can control zone level, source selection, mutes, level adjustment, scene/preset recall, and more.Low MaintenanceThe IP4 automatically matches firmware with connected devices for easy install and system maintenance.Mix and MatchMultiple IP Controllers can be connected to an AHM system to provide control exactly where needed.Use IP controllers of different flavors to suit the needs of your end users, even letting one controller change what other controllers are doing to reflect changes in the space.ConnectIP4 interfaces with the AHM system via standard TCP/IP Network connections and can be networked with other controllers, computers and third party devices using a standard Ethernet infrastructure.ConfigureIP4’s controls and functions are configured using AHM System Manager.

SQ Waves provides any SQ / SQ+ or AHM with a 64×64, 96kHz or 48kHz interface to a Waves SoundGrid network using the I/O Port.Recording, Effects and MoreEngineers or installers can now fit the Waves card to any SQ or AHM for Waves plugin processing, multitrack recording (at 96kHz or 48kHz), virtual soundcheck and audio distribution applications.

The DX164-W is a wall mountable expander that adds remote I/O to a dLive, Avantis, SQ and Qu* mixers, or to AHM audio matrix processors.16 Mic Preamps+60dB of gain, Phantom Power indicators and -20dB pad for line level sources.4 Line OutsBalanced, relay protected line outputs on XLR.Redundant and Cascade ModesRedundant mode supports dual-cable connection to compatible hardware. Cascade mode allows daisy-chaining of up to 2 DX Expanders on each DX port.Plug-and-PlayNo configuration required, just connect to your mixer and you’re ready to go. Firmware updates are handled automatically by the mixer.Wall or Floor MountThe reversible mounting frame allows for in-wall or on-wall mounting. With custom brackets, the unit can be fitted in a standard NEMA box, or mounted in a floor pocket for stage use.Put It Where You Need ItThe DX164-W can be placed up to 100m away from the mixer for maximum flexibility of positioning. The expander connects via a single Cat5e cable to the mixer or upstream DX Expander via a secure EtherCon port. A second locking EtherCon port is provided for redundant connection to compatible hardware, or for daisy-chaining to a downstream DX Expander for additional remote I/O.Flexible Power OptionsThe IEC mains power inlet can be replaced with a gland module and screw terminals for fixed installation, and a DC 12V backup input is also provided.*96kHz Qu models only
