ALLEN & HEATH SQ7+
Produktinformationen "ALLEN & HEATH SQ7+"
48 Channel / 44 Bus / 33 Fader Digital Mixer with RackUltra FX
The SQ7+ is the largest mixer in the range, built for engineers who need the ultimate in hands-on control. 33 motorised faders, 16 assignable SoftKeys and 8 SoftRotaries put your entire show within reach, all backed by the same 96kHz XCVI core and 4 built-in RackUltra FX engines that power every SQ+ model.
- 32+1 Onboard Preamps
- 18 Line Outputs
- 32+1 Faders / 6 Layers
- 16 Assignable SoftKeys
- 8 Assignable Soft Rotaries
- 96kHz FPGA Processing
- 48 Input Channels
- DEEP Processing Ready
- 8 RackExtra FX Engines + dedicated send and returns
- 4 RackUltra FX Engines + dedicated send and returns
- 12 Stereo Mixes + LR
- 3 Stereo Matrix
- Intelligent 128×128 SLink port
- Range of Remote Expanders
- 64×64 I/O Port for Audio Networking
- 32×32 USB Audio Interface
- 9” Touchscreen with dark GUI
Anmelden
Produktgalerie überspringen
Zubehör
ALLEN & HEATH SQ Dante 64x64
SQ Dante provides any SQ / SQ+ mixer or AHM processor with a full 64×64 channel, 96kHz or 48kHz interface to a Dante network.Expand Your System With DanteAn SQ or AHM unit fitted with the Dante option card can seamlessly connect to DT expanders, wireless systems, amplifiers, preamps and any other devices on your Dante network, making full use of high-resolution 96kHz audio.The SQ Dante card can be switched between 96kHz or 48kHz to accommodate Dante networks running at either sample rate. In addition to facilitating system integration, the card also enables digital splits and affordable multitrack recording direct to a computer.Add Dante to AHM Matrix ProcessorsSQ Dante V2& V3 share all the features and specifications of the V1 module, with no differences for SQ users*, but the V2 & V3 modules can also be fitted and used in an AHM matrix processor.*SQ firmware V1.5 or higher required.
ALLEN & HEATH GX4816
GX4816 is a 96kHz audio expander that provides high-input-count remote expansion for Qu*, SQ, Avantis and dLive mixing systems, and for AHM audio matrix processors.48 Mic Preamps+60dB of gain, Phantom Power indicators and -20dB pad for line level sources.16 Line OutsBalanced, relay protected line outputs on XLR.DX PortsA pair of DX ports enable connection of additional DX expanders or the ME Personal Monitoring System (not on dLive or AHM)Plug-and-PlayNo configuration required, just connect to your mixer and you’re ready to go. Firmware updates are handled automatically by the mixer.Massively Expand Your System I/O!Each GX4816 is loaded with 48 dLive mic preamps with independent Phantom Power LED indicators, plus 16 XLR line outputs. Additionally, 2 DX ports are provided for connection to up to 4 DX Expanders for further I/O expansion.Put It Where You Need ItThe GX4816 can be placed up to 100m away from the mixer for maximum flexibility of positioning and features integrated rack-ears for mounting in a 5U 19″ space.*96kHz Qu models only
ALLEN&HEATH SQ SLink
SQ SLink bietet die Möglichkeit, jedem SQ- oder AHM-Mixer einen intelligenten SLink-Port hinzuzufügen.Für SQBei SQ läuft die Optionskarte unabhängig vom integrierten SLink-Port, sodass zwei verschiedene Allen & Heath-Protokolle gleichzeitig in einem System verwendet werden können. Mit zwei SLink-Ports ist es jetzt möglich, einen SQ mit jedem ME-Personal-Monitoring-System, DX-, GX- oder dSnake-Expander zu kombinieren.Jede mit einer SLink-Karte ausgestattete SQ-Konsole kann auch direkt an ein Qu-, SQ-, Avantis- oder dLive-System angeschlossen werden, wodurch FOH-/Monitor-Splits, Broadcast-Feeds und mehr ermöglicht werden.Für AHMDie SQ SLink-Karte bietet AHM-16- und AHM-32-Prozessoren Zugriff auf die Everything I/O-Reihe von Audio-Expandern und fügt AHM-64 weitere I/O-Funktionen hinzu.Auf AHM-64 läuft die Optionskarte unabhängig vom integrierten SLink-Port, sodass zwei verschiedene Allen & Heath-Protokolle gleichzeitig in einem System verwendet werden können.
ALLEN & HEATH AB168
AB168 is a 48kHz portable remote AudioRack for use with Qu, Avantis and SQ mixers, and with AHM audio matrix processors.16 Mic Preamps+60dB of gain, Phantom Power indicators and -20dB pad for line level sources.8 XLR Line OutsBalanced, relay protected line outputs on XLR.Expander PortFor daisy-chaining 2 compatible Expanders or connection to ME personal mixers.Plug-and-PlayNo configuration required, just connect to your mixer and you’re ready to go. Firmware updates are handled automatically by the mixer.Ready for the StageThe Expander’s rugged design, with hard-wearing rubber bumpers, allows it to be placed directly on the stage floor during performances. Weighing in at just 4.8kg and featuring a sturdy carry handle, the AB168 offers the convenience and portability needed in rental, education, houses of worship and many other environments. An optional 4U rack mounting kit is available for installation in 19-inch racks.Put It Where You Need ItThe AB168 can be placed up to 100m away from the mixer for maximum flexibility of positioning. The unit connects over a single Cat5 cable to the mixer or upstream Expander. A second port is provided for daisy-chaining to another compatible expander or for connection to a ME personal mixing system.
ALLEN & HEATH SQ Dante 32x32
SQ Dante 32×32 provides any SQ / SQ+ mixer or AHM processor with a full 32×32 channel, 96kHz or 48kHz interface to a Dante network.Expand Your System With DanteAn SQ or AHM unit fitted with the Dante option card can seamlessly connect to DT expanders, wireless systems, amplifiers, preamps and any other devices on your Dante network, making full use of high-resolution 96kHz audio.The SQ Dante card can be switched between 96kHz or 48kHz to accommodate Dante networks running at either sample rate. In addition to facilitating system integration, the card also enables digital splits and affordable multitrack recording direct to a computer.Add Dante to AHM Matrix ProcessorsThe SQ Dante 32×32 card is the perfect partner to the AHM-32 and AHM-16 Audio Matrix Processors.As well as making it easy to integrate AHM processors into existing Dante networks, it also enables use of our Dante enabled expanders, including the compact and portable DT22, DT02 and DT20, the wallmountable DT164-W, and the DT168 stagebox.
ALLEN & HEATH DX HUB
DX Hub provides 4 DX Link ports each carrying 32×32 channels of 96kHz audio, that can be used to connect up to 8 DX expander units.Massively Expand I/OEach of the 4 DX sockets can support up to 2 DX168/DX164-W/DX012 Expanders or 1 DX32 expander.Rack MountableOptional 19-inch rackmount kit available for fixed installations or touring.Redundant ModeA pair of DX Hubs can be used for dual-cable connection to compatible dLive hardware.Single Cable TrunkA single CAT5 run from the DX Hub to your mixer reduces cabling requirements.Your I/O HubDX Hub provides 4 DX Link ports each carrying 32×32 channels of 96kHz audio, that can be used to connect to DX expander units.Up to 2 DX expanders can be connected to each DX Link port allowing up to 128 remote inputs and 64 remote outputs to be added to the system. Multiple DX Hubs can be used for further expansion, or for dual redundancy (dLive only)Simplify Cable RunsDX Hub is particularly suited to Install and Commercial Audio applications and any environment where it is desirable to run a single “trunk” CAT5e cable to the DX Hub from the AHM, dLive, Avantis or SQ system.An optional rack mount kit is available for installation in a 1U 19″ rack space.DX Hub CompatibilityDX Hub can be connected to any AHM, SQ, Qu*, or Avantis mixer via SLink, or any Avantis mixer or dLive system fitted with a gigaACE I/O module.*96kHz Qu models only
ALLEN & HEATH SQ Waves
SQ Waves provides any SQ / SQ+ or AHM with a 64×64, 96kHz or 48kHz interface to a Waves SoundGrid network using the I/O Port.Recording, Effects and MoreEngineers or installers can now fit the Waves card to any SQ or AHM for Waves plugin processing, multitrack recording (at 96kHz or 48kHz), virtual soundcheck and audio distribution applications.
ALLEN & HEATH Tablet Bracket fur SQ Serie
The steel tablet bracket screws into the rear of your SQ / SQ+– perfect for using an iOS or Android device running SQ MixPad to extend touchscreen control and visual feedback. SQ-7 / SQ-7+ has a choice of mounting options for a single bracket or a pair of brackets.
ALLEN & HEATH DX88-P
The DX88 provides 8 inputs and 8 outputs on Phoenix / Euroblock connectors for fixed installations and is an easy way to add local or remote expansion to AHM Audio Matrix Processors.8 Ins + OutsEight mic/line inputs with +60dB of gain, phantom power and -20dB pad, and eight line outputs, all on Phoenix/Euroblock connectors.RackmountableA rackmount kit is available for installing two DX88 expanders together. DX88 can also be installed alongside a GPIO or DX Hub with an additional kit.Cascade ModeCascade mode allows daisy-chaining of up to 2 DX Expanders on each DX port.Plug-and-PlayNo configuration required, just connect to your mixer and you’re ready to go. Firmware updates are handled automatically by the mixer.Easily Add Phoenix / Euroblock Inputs and Outputs via a DX ConnectionDX88 is a 96kHz DX expander enabling convenient placement of 8 mic/line inputs and 8 line outputs – via standard Phoenix / Euroblock connectors – wherever you need to get additional analogue audio in and out of a fixed install.Put It Where You Need ItThe DX88-P can be placed up to 100m away from the mixer for maximum flexibility of positioning.The expander connects via a single Cat5e cable to the mixer or upstream DX Expander via the DX A port. A second RJ45 port, DX B, is provided for daisy-chaining to a downstream DX Expander for additional remote I/O.Rack Mount KitAn optional rack mount kit is available for installation of up to two DX88-P units in a 1U 19″ slot to interface with analogue equipment such as an AV switcher.The DX88-P can also be rack mounted alongside a DX Hub or GPIO module by combining the optional rack kit with the DX Hub / GPIO rack kit.
ALLEN & HEATH DX164-W
The DX164-W is a wall mountable expander that adds remote I/O to a dLive, Avantis, SQ and Qu* mixers, or to AHM audio matrix processors.16 Mic Preamps+60dB of gain, Phantom Power indicators and -20dB pad for line level sources.4 Line OutsBalanced, relay protected line outputs on XLR.Redundant and Cascade ModesRedundant mode supports dual-cable connection to compatible hardware. Cascade mode allows daisy-chaining of up to 2 DX Expanders on each DX port.Plug-and-PlayNo configuration required, just connect to your mixer and you’re ready to go. Firmware updates are handled automatically by the mixer.Wall or Floor MountThe reversible mounting frame allows for in-wall or on-wall mounting. With custom brackets, the unit can be fitted in a standard NEMA box, or mounted in a floor pocket for stage use.Put It Where You Need ItThe DX164-W can be placed up to 100m away from the mixer for maximum flexibility of positioning. The expander connects via a single Cat5e cable to the mixer or upstream DX Expander via a secure EtherCon port. A second locking EtherCon port is provided for redundant connection to compatible hardware, or for daisy-chaining to a downstream DX Expander for additional remote I/O.Flexible Power OptionsThe IEC mains power inlet can be replaced with a gland module and screw terminals for fixed installation, and a DC 12V backup input is also provided.*96kHz Qu models only
ALLEN & HEATH DX168
The DX168 is a rugged, 96kHz portable expander for adding remote I/O to a dLive, Avantis, SQ, or Qu* system, or to AHM audio matrix processors.16 Mic Preamps+60dB of gain, Phantom Power indicators and -20dB pad for line level sources.8 Line OutsBalanced, relay protected line outputs on XLR.On Stage or In The RackRugged stagebox format with optional rackmount kit available.Plug-and-PlayNo configuration required, just connect to your mixer and you’re ready to go. Firmware updates are handled automatically by the mixer.Ready for the StageThe Expander’s rugged design, with hard-wearing rubber bumpers, allows it to be placed directly on the stage floor during performances. Weighing in at just 4.8kg and featuring a sturdy carry handle, the DX168 offers the convenience and portability needed in rental, education, houses of worship and many other environments. An optional 4U rack mounting kit is available which allows installation in 19-inch racks.Put It Where You Need ItThe DX168 can be placed up to 100m away from the mixer for maximum flexibility of positioning. The expander connects via a single Cat5e cable to the mixer or upstream DX Expander via a secure EtherCon port. A second locking EtherCon port is provided for redundant connection to compatible hardware, or for daisy-chaining to a downstream DX Expander for additional remote I/O.*96kHz Qu models only
ALLEN & HEATH DX012
DX012 provides remote output expansion for Qu*, SQ, Avantis and dLive mixers, and for AHM audio matrix processors.12 XLR OutsFlexible switching options between balanced, relay protected analogue and stereo AES digital on outputs 5-12.AES CompatibleAES outputs globally switchable between 44.1kHz,48kHz, 88.2kHz or 96kHz.Redundant & Cascade ModesRedundant mode supports dual-cable connection to compatible hardware. Cascade mode allows daisy-chaining of up to 2 DX Expanders on each DX port.Plug-and-PlayNo configuration required, just connect to your mixer and you’re ready to go. Firmware updates are handled automatically by the mixer.Need to get more out of your system?Perfect for feeding IEM systems and amplifier racks, DX012 offers both analogue and AES digital output options in a compact 1U form factor.Put It Where You Need ItThe DX012 can be placed up to 100m away from the mixer for maximum flexibility of positioning and features integrated rack-ears for mounting in a 1U 19″ space. The expander connects via a single Cat5e cable to the mixer or upstream DX Expander via a secure EtherCon port. A second locking EtherCon port is provided for redundant connection to compatible hardware, or for daisy-chaining to a downstream DX Expander for additional remote I/O.Flexible Output OptionsThe DX012 provides 12 XLR outputs, with three configuration options:12 analogue line outputs8 analogue line outputs + 4 stereo AES outputs4 analogue line outputs + 8 stereo AES outputs*96kHz Qu models only
